EFD80
Enhanced Monitoring and Control with EFD80 I/O Board
I/O Board
Flexible and Secure I/O Expansion for Comprehensive System Integration
The EFD80 I/O Board offers reliable input-output expansion with tamper detection and robust functionality, perfect for enhancing system control and security.
EFD80
I/O Board
The EFD80 I/O Board provides seamless integration with a wide range of systems, offering flexible output expansion and onboard supervision for enhanced operational efficiency.
Onboard Supervised Inputs
Comes with 16 input points for monitoring doors, sensors, and alarms.
Onboard Relay Outputs
Includes 8 relay outputs to control locks, alarms, or automation devices.
Expandable Output Capacity
Supports up to 24 output points for future system expansion.
Built-In Tamper Detection
Integrated tamper detection ensures system integrity and prevents unauthorized access.
Wide Operating Temperature Range
Designed to operate reliably across various environmental conditions.
Meet the EFD80
Model
Manufacturer
Country of Origin
Microprocessor
Onboard Supervised Inputs
Onboard Relay Outputs
Output Expansion Capacity
Power Supply
Dimension
Operating Temperature
Humidity
Power Requirements
Casing Dimensions
Approximate Weight
EFD80 (ES1608)
ELID Sdn Bhd
Malaysia
Motorola 68 HC908 GP32 PLL at 4.9 Mhz
16 Input Points
8 Output Points
24 Output Points
12VDC
350 (H) X 240 (H) X 80 (D) mm
0⁰ C to 50⁰ C
10% to 90% non-condensing
12VDC 100mA excluding reader
410 (H) X 400 (L) X 120 (W) mm
7Kg
